LED / Optical Communications
Assembly and precision material application for LED modules, drivers and optical communication electronics.
Typical Applications
- LED lighting modules and driver boards
- Optical communication modules and their electronic assemblies
- Connector, housing and selected sealing applications
Process Planning
01 · Review the module design
Identify optical surfaces, connectors, sensitive components and areas that must remain free of adhesive or coating.
02 · Plan assembly and inspection
Match the board format and component layout to the assembly flow and required optical inspection coverage.
03 · Control dispensing and protection
Evaluate dispensing paths and selective coating against the material, working area and module access requirements.
What to Share With JCX
- Module drawings, PCB dimensions and component-height information
- Optical and electrical keep-out areas
- Material specifications, target deposits and inspection criteria
Equipment and process configuration are reviewed against your drawings, materials, samples and acceptance criteria.
Equipment to Evaluate
Use these configurations as starting points for an application review. Click a product card to read its specifications and options.
Match the Process to the Configuration
| Process | Model to review | Starting point | Confirm before selection |
|---|---|---|---|
| Module bonding / local dispensing | G201-F3 | Evaluate material deposits around accessible module features. | Confirm optical cleanliness, adhesive behaviour, alignment method and cure. |
| LED / driver-board assembly | Venus 510 3D AOI | Review visible component placement and solder-joint features. | Match board size, optics and defect criteria; electrical or optical performance tests remain separate. |
| Driver-board protection | G210-F3 Series | Review selective coating around accessible board areas. | Protect optical surfaces and connectors; qualify coating and keep-out boundaries. |
Optical coupling, active alignment and optical-output testing require separately specified processes. Dispensing equipment alone should not be treated as an optical alignment system.
Plan Your Application With JCX
Share your product drawings and process requirements so we can discuss the equipment configuration and next steps.
