Consumer Electronics
Flexible assembly, inspection and dispensing for compact devices, wearables and connected consumer products.
Typical Applications
- Smart devices, wearables and connected accessories
- Audio products and compact electronic modules
- Home appliances and personal electronics control boards
Process Planning
01 · Prepare for product variety
Review board families, frequent changeovers, compact layouts and new-product introduction requirements.
02 · Inspect dense assemblies
Select inspection configuration around fine-pitch components, small solder joints and the customer's defect criteria.
03 · Review precision dispensing
Evaluate adhesive, sealing and reinforcement locations with representative parts and the specified material.
What to Share With JCX
- Product mix, PCB dimensions and annual production plan
- Small-component and fine-pitch inspection requirements
- Material datasheets, dispensing drawings and changeover targets
Equipment and process configuration are reviewed against your drawings, materials, samples and acceptance criteria.
Equipment to Evaluate
Use these configurations as starting points for an application review. Click a product card to read its specifications and options.
Match the Process to the Configuration
| Process | Model to review | Starting point | Confirm before selection |
|---|---|---|---|
| FPC / small-assembly dispensing | G201-F3 | Review reinforcement or underfill deposits with vision positioning. | Confirm fixture support, adhesive, access and production changeover. |
| Paste process review | Ican 510 3D SPI | Measure printed paste before placement. | Provide pad and stencil data, samples and acceptance limits. |
| Visible assembly inspection | Isee 510 2D AOI | Evaluate a 2D inspection route for suitable visible components. | Assess the defects and viewing conditions; choose 3D AOI where height information is required. |
Small parts, reflective surfaces and dense layouts should be evaluated with representative samples. Minimum-feature claims depend on the selected optics and process.
Plan Your Application With JCX
Share your product drawings and process requirements so we can discuss the equipment configuration and next steps.
