Dimension Size: L 950 * W 1250 * H 1600 mm
PCB Size: L 50 * W 50~ L 360 * W 320mm Max. Thickness 6mm
Min. Inspection Height of Component: From 0201 metric
Max. Inspection Height of Component: 35mm
PCB Flow of Direction: Left to right, right to left, left to left, right to right (Adjust in programming)
Side Camera: Option
Main Camera’s Number of Megapixel: 12M ( Option 21M )
Main Camera’s Resolution: Standard 12um ( Option 15um / 7um / 10um ）
Max. Transport Clearance: Top 50mm , Bottom 50 mm
Max.PCB Bending Adjustment : ±4 mm
Power Requirements: 200-240V AC 50/60HZ
Power Consumption: Standard 500W, Max. 800W
Operating System: Window 10
Confirm PCB dimensions, track use, optical configuration, component clearance and inspection acceptance criteria with JCX before ordering.
