Dimension Size： L 1400 * W 1600 * H 1600mm
PCB Size ： Same PCB：L 50 * W 50~ L 810 * W 320mm Max. Thickness 6mm
Different PCB：L 50 * W 50~ L 810 * W 590mm Max. Thickness 6mm
Min. Inspection Height of Component: From 0201 metric
Max. Inspection Height of Component: 35mm
Main Camera’s Number of Megapixel: 12M ( Option 21M )
Main Camera’s Resolution: Standard 15um ( Option 12um / 7um / 10um ）
Max. Transport Clearance: Top 50mm , Bottom 50 mm
Max.PCB Bending Adjustment : ±4 mm
PCB Flow of Direction: Left to right, right to left, left to left, right to right (Adjust in programming)
Side Camera: Option
Power Requirements: 200-240V AC 50/60HZ
Power Consumption: Standard 600W, Max. 850W
Operating System: Window 10
Confirm PCB dimensions, track use, optical configuration, component clearance and inspection acceptance criteria with JCX before ordering.
